Conventional piling equipment often suffers from complicated operation, insufficient accuracy, and poor adaptability in positioning and attitude adjustment. To address these challenges, the KT Series Swing-Type Pile Driver has been developed, offering both precise positioning and flexible attitude control. The rotary mechanism enables 360° high-precision positioning to meet multi-directional construction needs, while the swing mechanism allows flexible adjustment of the hammer’s orientation, ensuring reliable performance in complex terrains and demanding construction environments.
※ Product Features

1. Working Principle

The KT Tilt Vibratory Hammer combines vibration and hammering force to help piles sink quickly into the ground. It generates high-frequency vibrations, reducing soil friction and allowing piles to penetrate easily. The tilt function allows the hammer head to be adjusted at an angle to suit different geological conditions and project requirements.

2. Key Features

High Efficiency: The combination of vibration and tilting significantly improves piling efficiency and reduces construction time.

Flexible Tilt Angle: The hammer can be freely adjusted between multiple angles to accommodate different types of pile foundations and geological conditions.

Reduced Noise and Vibration: Compared to traditional piling methods, the vibration hammer significantly reduces noise and vibration, helping to minimize environmental impact.

Wide Application: Suitable for a wide range of geological conditions, including sand, clay, rock, and other soil types.

High-Precision Positioning: The hammer can precisely control the location and depth of piles, ensuring pile foundation stability and structural safety.

Easy Operation: The advanced control system makes operation simple and safe, improving construction worker efficiency.

3. Technical Specifications

Vibration Frequency: Depending on the specific model, the vibration frequency is adjustable, typically between 1.000 and 2.500 vibrations per minute.

Maximum Piling Depth: Up to 60 meters (specific depth varies depending on geology and pile type).

Maximum Tilt Angle: Typically adjustable up to 25 degrees, helping to adapt to complex terrain.

Power Source: Typically a hydraulic drive system, ensuring stable power output.

4. Applications

Building Foundations: Widely used in large-scale infrastructure projects such as high-rise buildings, bridges, and ports.

Foundation Reinforcement: Used to enhance the bearing capacity of foundations, especially in soft soils.

Marine Engineering: Also widely used in marine projects such as offshore platforms and breakwaters.

Environmental Protection: Due to its low noise and vibration characteristics, it is also suitable for piling construction in urban environments.

5. Advantages

Increased Construction Speed: The combined vibration and tilting functions significantly reduce piling time.

Reduced Environmental Impact: Through meticulous noise and vibration control, it's suitable for construction in urban areas or sensitive areas.

Cost Savings: Compared to traditional methods, vibratory hammers significantly reduce additional costs during the construction process.

HberTech Pile Driving Equipment Co., Ltd. is a high-tech enterprise that develops and manufactures intelligent types of equipment. The company has passed the ISO9000 quality system certification (certificate number: NOA1824367). The equipment has the characteristics of low weight, high excitation force, low noise, low wear and long life.
Excavator Mounted Vibratory Hammers, Side Grip Vibro Hammers and Excavator Dredge Pump Attachment produced by us are mobile and flexible. The foundation construction has entered a new stage which significantly saves construction costs and improves work efficiency. The developed products have obtained several invention patents.
